-기본 사양
• Four instruments in one (voltage source, voltage measure, current source, current measure)
• Wide Dynamic Range:
– Will source voltage from 100μV to 1100V, and current from 100fA to 100mA
– Will measure voltage from 10μV to 110V and current from 10fA to 100mA
– In the higher voltage range, current source and measure is 10mA maximum
• Selectable Sweeps of Voltage and Current:
– Programmable to perform source-measurements as a function of a stepped voltage or current. Voltage
• Wide Dynamic Range:
– Will source voltage from 100μV to 1100V, and current from 100fA to 100mA
– Will measure voltage from 10μV to 110V and current from 10fA to 100mA
– In the higher voltage range, current source and measure is 10mA maximum
• Selectable Sweeps of Voltage and Current:
– Programmable to perform source-measurements as a function of a stepped voltage or current. Voltage
and current can be swept linearly, logarithmically, or pulsed.
• Outputs and inputs are fully guarded, and the units are configured to allow four-terminal measurements
• Two-terminal measurements also available and these outputs can be floated up to ±200V from ground
• 10fA, 10µV measurement sensitivity
• 1100V source and measure
• Standard and custom sweep capability including pulse
• 1000 source/measurements per second
• Four quadrant source operation
• Internal 1000-reading memory
• Outputs and inputs are fully guarded, and the units are configured to allow four-terminal measurements
• Two-terminal measurements also available and these outputs can be floated up to ±200V from ground
• 10fA, 10µV measurement sensitivity
• 1100V source and measure
• Standard and custom sweep capability including pulse
• 1000 source/measurements per second
• Four quadrant source operation
• Internal 1000-reading memory
